Server Technology PRO1 Smart PDU C1S14CS-2CBA150 - Master - power distribution unit (rack-mountable) - AC 208 V - 5 kW - Ethernet 10/100, RS-232 - input: NEMA L6-30P - output connectors: 14 (14 x IEC 60320 C13)

• Network monitoring
  Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
• Hot swappable
  Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit.
• Multi link expansion
  Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
• Enviromental monitoring
  Master and Link units each support two external 10' (3m) T/H probes. Receive SNMP-based alerts and email notifications.
• Input current monitor
  Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
• High retention outlets
  Receptacles have high retention and are compatible with P-Lock type power cords.
• Flexible mounting
  Includes standard button mounts along with provisions for custom mounting brackets.

The Server Technology PRO1 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements, are accessible through the built-in Web and CLI interfaces as well as through SNMP.

• Network monitoring
• Hot swappable
• Multi link expansion
• Enviromental monitoring
• Input current monitor
• High retention outlets
• Flexible mounting
